Chapter 3 Opening and Closing the HP NetServer
32
Removing the Pedestal
The pedestal version of the HP NetServer LC 2000 mounts to an anti-tip pedestal,
which can be easily removed, if necessary.
1. Perform Steps 1-4 in the previous section, "Removing Covers – Pedestal
(LC 2000)."
NOTE The front bezel is shown removed, but the bezel may remain on
the chassis while removing the pedestal.
2. Disconnect all cables connected to the rear of the NetServer that would
limit its rotation before continuing.
3. Turn the NetServer over onto its top and pull up on the two tabs as shown
in Figure 3-9.
Figure 3-9. Removing the Pedestal
4. Slide the pedestal to the rear of the NetServer as shown in Figure 3-9.
5. To re-install the pedestal, repeat Steps 1-3 and slide the pedestal forward
onto the NetServer.
