To Enable Arbitrary Waveform
Press Arb to enable arbitrary waveform function and open the operation menu of
arbitrary waveform.
1. Freq/Period: set the output “Frequency/Period” of the arbitrary waveform.
2. Ampl/HiLevel: set the output “Amplitude/High Level” of the arbitrary
waveform.
3. Offset/LoLevel: set the output “Offset/Low Level” of the arbitrary waveform.
4. Phase: set the “Start Phase” of the arbitrary waveform.
5. Align Phase: refer to Align Phase.
6. Point By Point: enable the point by point output mode of arbitrary waveform.
7. Select Wform: select arbitrary waveform stored in internal or external
memory.
8. Create New: users can define waveform with up to 16 kpts.
9. Edit Wform: edit the stored arbitrary waveform.
Refer to Basic Waveform Output to configure the parameters and output. This
chapter will focus on “Point By Point”, “Select Waveform”, “Create New” and “Edit
Waveform”.
Tip
Users can also press User at the front panel to quickly set arbitrary waveform
parameters including frequency/period, amplitude/high level, offset/low level,
start phase and align phase. At this point, the waveform output is the waveform
defined in Utility  UserKey (refer to introduction in User-defined
Waveform Key).
