Chapter 13 Specifications RIGOL
DG4000 Series User’s Guide 13-1
Chapter 13 Specifications
All the specifications can be guaranteed if the following two conditions are met
unless where noted.
 The generator is within the calibration period and has performed
self-calibration.
 The generator has been working continuously for at least 30 minutes under
the specified temperature (18℃ ~ 28℃).
All the specifications are guaranteed unless those marked with “typical”.
Model DG4162 DG4102 DG4062
Channel 2 2 2
Maximum Frequency 160MHz 100MHz 60 MHz
Sample Rate 500MSa/s
Waveforms
Standard waveforms
Sine, Square, Ramp, Pulse, Noise, Harmonics
Arbitrary Waveforms 150 kinds, including Sinc, Exponential Rise, Exponential Fall, ECG,
Gauss, HaverSine, Lorentz, Dual-Tone, DC, etc.
Frequency Characteristics
Sine
1μHz to 160MHz 1μHz to 100MHz 1μHz to 60MHz
Square 1μHz to 50MHz 1μHz to 40MHz 1μHz to 25MHz
Ramp 1μHz to 4MHz 1μHz to 3MHz 1μHz to 1MHz
Pulse 1μHz to 40MHz 1μHz to 25MHz 1μHz to 15MHz
Harmonic 1μHz to 80MHz 1μHz to 50MHz 1μHz to 30MHz
Noise (-3dB) 120MHz bandwidth 80MHz bandwidth 60MHz bandwidth
Arbitrary Waveform 1μHz to 40MHz 1μHz to 25MHz 1μHz to 15MHz
Resolution 1μHz
Accuracy ±2ppm, 18℃ to 28℃
Sine Wave Spectrum Purity
Harmonic Distortion
Typical (0dBm)
DC-1MHz: <-60dBc
