Using Optional Camera Accessories A-3
A
B
Using an Optional Tripod
You can use your PhotoPC 650 with any standard tripod.
Follow these steps:
1 Assemble and set up the tripod by following the
manufacturer’s instructions. Make sure the tripod is
well-balanced on a flat surface.
2 Find the threads for the tripod screw on the bottom of
your camera.
3 Carefully place the camera on the tripod, then screw it
on until it is firmly in place. Adjust the tripod to view
your subject as desired.
Using Optional Lenses
The built-in 37 mm threads on your camera let you attach
wide-angle, telephoto, and other types of 37 mm video
camcorder lenses and filters.
The following table shows the minimum distance from the
subject, the diagonal angle of view, and the millimeter
equivalents for wide-angle, close-up, and telephoto lenses
from Tiffen:
NOTE
For the best results, use lenses that screw directly onto the
camera, not the type that clip on with tabs.
To attach a lens, simply twist it onto the 37 mm threads in
the front of your camera, as shown in the next sections.
tripod threads
Lens type Nearest subject
Diagonal angle
of view
Equivalent lens
Standard 20 in. 45 ° 36 mm
Telephoto 7.5 ft 30 ° 76 mm
Wide angle (0.65X) 1.5 ft 65 ° 22.5 mm
+7 diopter close-up 2.5 in. — —
+10 diopter close-up 1.5 in. — —
