8  Reactive Power Control

SMA America, LLC

56

SCCP-US-BE-US_en-52

Operating Manual

8 Reactive Power Control

The inverter can supply reactive power if required by the grid operator. The grid operator defines the procedures and

setpoints used for this.

8.1 Selecting Reactive Power Control Procedure with the Parameter

Q-VArMod

You can set the procedure for reactive power regulation via the parameter Q-VArMod. Use the parameter to configure

how the specifications of the grid operator are to be received and implemented.
There are eleven different procedures for reactive power regulation. The default setting for this parameter is Off.

/05*$&

Operation failure of the inverter due to incorrectly set parameters
If the parameter settings for grid management services are incorrect, the inverter may not be able to meet the grid

management requirements. This may lead to yield losses and disconnection of the inverter by the grid operator.

• When setting the mode of grid management services, ensure that the control procedures are parameterized as

agreed with the grid operator.

Procedure

Description

Off

The reactive power setpoint is limited to 0 kVAr.

VArCtlCom

The reactive power target value is received by the SC-COM via Modbus and then transmitted to

the inverter.
The target value is transmitted as a percentage.

PFCtlCom

The reactive power target value is received by the SC-COM via Modbus and then transmitted to

the inverter. A displacement power factor cos φ is transmitted as a setpoint.

VArCnst

The parameter Q-VAr is used to set the reactive power setpoint in kVAr.

VArCnstNom

The parameter Q-VArNom is used to set the reactive power setpoint as a percentage based on

Pmax.

VArCnstNomAnIn

The reactive power setpoint is imported via an analog input. The analog value is converted into

a reactive power setpoint.

PFCnst

The reactive power target value is set using a displacement power factor cos φ.

PFCnstAnIn

The reactive power setpoint is imported via the analog input for the setpoint. The analog value is

converted into a displacement power factor cos φ.

PFCtlW

The displacement power factor cos φ is set depending on the feed-in power. The dependency is

depicted by a parameterizable characteristic curve.

VArCtlVol

Reactive power is set depending on the line voltage. The parameterization of this function is

based on the medium voltage.

VArCtlVolHystDb

The supply of reactive power helps perform voltage-stabilizing measures in the event of

overvoltage or undervoltage. The parameterization is performed using a reactive power/voltage

characteristic curve.

VArCtlVolHysDbA

The provision of reactive power helps perform voltage-stabilizing measures in the event of

overvoltage or undervoltage. The parameterization is carried out by means of a reactive power/

voltage characteristic curve and an activation power.
