3.87. OSPFProcess
Description
An OSPF Router Process defines a group of routers exchanging routing information via the Open
Shortest Path First routing protocol.
Properties
Name Specifies a symbolic name for the OSPF process.
(Identifier)
RouterID Specifies the IP address that is used to identify the
router. If no router ID is configured, it will be
computed automatically based on the highest IP
address of any interface participating in the OSPF
process. (Optional)
PrivRouterID The private router ID of this high availability node.
(Optional)
RFC1583 Enable this if the security gateway will be used in a
environment that consists of routers that only
support RFC 1583. (Default: No)
SPFHoldTime Specifies the minimum time, in seconds, between
two SPF calculations. (Default: 10)
SPFDelayTime Specifies the delay time, in seconds, between
when OSPF receives a topology change and when
it starts a SPF calculation. (Default: 5)
LSAGroupPacing This specifies the time in seconds at which interval
the OSPF LSAs are collected into a group and
refreshed. (Default: 10)
RoutesHoldtime This specifies the time in seconds that the routing
table
will be kept unchanged after a
reconfiguration of OSPF entries or a HA failover.
(Default: 45)
RefBandwidthValue Set the reference bandwidth that is used when
calculating the default interface cost for routes.
(Default: 1)
RefBandwidthUnit Sets the reference bandwidth unit. (Default: Gbps)
MemoryMaxUsage Maximum amount in bytes of RAM that the OSPF
process is allowed to use. The default is one
percent of installed RAM. Specifying 0 indicates
that the OSPF process is allowed to use all available
RAM. (Optional)
DebugPacket Enables or disabled logging of general packet
parsing events and also specifies the details of the
log. (Default: Off )
DebugHello Enables or disabled logging of hello packets and
also specifies the details of the log. (Default: Off )
