Pin Assignments
MVME51005E Single Board Computer Installation and Use (6806800A38D) 93
Note: PIN 130, 131, MEZZ1_L, MEZZ2_L, configures the board’s local bus frequency. If a single
mezzanine is attached to the board, MEZZ1_L will be pulled down on the board. If a second
mezzanine is attached on-top to the first, MEZZ2_L will be pulled down on the board. This may
cause the clock generation logic to set the local bus frequency to 83.33 MHz if necessary.
99 GND GND 100
101 A08 A07 102
103 A06 A05 104
105 A04 A03 106
107 A02 A01 108
109 +3.3V +3.3V 110
111 A00 CS_E0_L 112
113 CS_E0_L GND 114
115 CS_E1_L CS_E0_L 116
117 WE_L RAS_L 118
119 GND GND 120
121 CAS_L +3.3V 122
123 +3.3V DQMB0 124
125 DQMB1 SCL 126
127 SDA A1_SPD 128
129 A0_SPD MEZZ2_L 130
131 MEZZ2_L GND 132
133 GND SDRAMCLK1 134
135 SDRAMCLK3 +3.3V 136
137 SDRAMCLK4 SDRAMCLK2 138
139 GND* GND* 140
Table 6-2 RAM500 Bottom Side Connector (P1)Pin Assignments (continued)
Pin Assignment Assignment Pin
