Page 89: Pin assignments
Pin Assignments
MVME51005E Single Board Computer Installation and Use (6806800A38D)
91
6.3.2
Memory Expansion Connector (J8) Pin Assignments
This connector is used to provide memory expansion capability. A single memory mezzanine
card provides a maximum of 256MB of memory. Attaching another memory mezzanine to the
first mezzanine provides an additional 512MB of expansion memory. The pin assignments for
this connector are as follows:
Table 6-2 RAM500 Bottom Side Connector (P1)Pin Assignments
Pin
Assignment
Assignment
Pin
1
GND*
GND
2
3
DQ00
DQ01
4
5
DQ02
DQ03
6
7
DQ04
DQ05
8
9
DQ06
DQ07
10
11
+3.3V
+3.3V
12
13
DQ08
DQ09
14
15
DQ10
DQ11
16
17
DQ12
DQ13
18
19
DQ14
DQ15
20
21
GND
GND
22
23
DQ16
DQ17
24
25
DQ18
DQ19
26
27
DQ20
DQ21
28
29
DQ22
DQ23
30
31
+3.3V
+3.3V
32
33
DQ24
DQ25
34
35
DQ26
DQ27
36
37
DQ28
DQ29
38
39
DQ30
DQ31
40
41
GND
GND
42
43
DQ32
DQ33
44
