Pin Assignments
MVME51005E Single Board Computer Installation and Use (6806800A38D) 113
Note: Rows A and C and Z’s (Z1, 3, 5, 7, 9, 11, 13, 15 and 17) functionality is provided by the
IPMC761 in slot 1 and the MVME5100 Ethernet port 2.
Pin Row Z Row A Row B Row C Row D
1 DB8# DB0# +5V TD+ PMC2_1 (J24-1)
2 GND DB1# GND TD- PMC2_3 (J24-3)
3 DB9# DB2# N/C RD+ PMC2_4 (J24-4)
4 GND DB3# VA24 AC Terminated PMC2_6 (J24-6)
5 DB10# DB4# VA25 AC Terminated PMC2_7 (J24-7)
6 GND DB5# VA26 RD- PMC2_9 (J24-9)
7 DB11# DB6# VA27 +12V (LAN) PMC2_10 (J24-10)
8 GND DB7# VA28 PRSTB# PMC2_12 (J24-12)
9 DB12# DBP# VA29 P DB0 PMC2_13 (J24-13)
10 GND ATN# VA30 P DB1 PMC2_15 (J24-15)
11 DB13# BSY# VA31 P DB2 PMC2_16 (J24-16)
12 GND ACK# GND P DB3 PMC2_18 (J24-18)
13 DB14# RST# +5V P DB4 PMC2_19 (J24-19)
14 GND MSG# VD16 P DB5 PMC2_21 (J24-21)
15 DB15# SEL# VD17 P DB6 PMC2_22 (J24-22)
16 GND D/C# VD18 P DB7 PMC2_24 (J24-24)
17 DBP1# REQ# VD19 P ACK# PMC2_25 (J24-25)
18 GND I/O# VD20 P BSY PMC2_27 (J24-27)
19 PMC2_29 (J24-29) TXD# VD21 P PE PMC2_28 (J24-28)
20 GND RXD3# VD22 P SEL PMC2_30 (J24-30)
21 PMC2_32 (J24-32) RTS3 VD23 P IME PMC2_31 (J24-31)
22 GND CTS3 GND P FAULT# PMC2_33 (J24-33)
23 PMC2_35 (J24-35) DTR3 VD24 TXD1_232 PMC2_34 (J24-34)
24 GND DCD3 VD25 RXD1 PMC2_36 (J24-36)
25 PMC2_38 (J24-38) TXD4 VD26 RTS1 PMC2_37 (J24-37)
26 GND RXD4 VD27 CTS1 PMC2_39 (J24-39)
