8 com1 and com2 connector pin assignments, Pin assignments – Artesyn MVME51005E SBC Installation and Use (July 2014) User Manual
Page 113
Pin Assignments
MVME51005E Single Board Computer Installation and Use (6806800A38D)
115
6.3.8
COM1 and COM2 Connector Pin Assignments
A standard RJ45 connector located on the front panel and a 9-pin header located near the
bottom edge of the MVME5100 provides the interface to the serial debug ports. The RJ45
connector is for COM1 and the 9-pin header is for COM2.
The pin assignments for these connectors are as follows:
Pin
Assignment
1
DCD
2
RTS
3
GNDC
4
TXD
5
RXD
6
GNDC
7
CTS
8
DTR
