Figure c-1, Thermal analysis – Artesyn MVME51005E SBC Installation and Use (July 2014) User Manual
Page 140
Thermal Analysis
MVME51005E Single Board Computer Installation and Use (6806800A38D)
142
Note: An MVME5100 Single Board Computer and an IPMC761 I/O board was tested in an
Artesyn lab environment, and it was verified that the reliability of the components would not
be compromised when operating in a maximum ambient temperature of 55 degrees C, if the
required airflow of 400 LFM is provided. Customer findings my differ based on specific
environmental and operational characteristics.
Figure C-1
Thermally Significant Components on the MVME5100 SBC - Primary Side
