Pin Assignments
MVME51005E Single Board Computer Installation and Use (6806800A38D) 107
29 AD51 AD50 30
31 AD49 GND 32
33 GND AD48 34
35 AD47 AD46 36
37 AD45 GND 38
39 +5V (Vio) AD44 40
41 AD43 AD42 42
43 AD41 GND 44
45 GND AD40 46
47 AD39 AD38 48
49 AD37 GND 50
51 GND AD36 52
53 AD35 AD34 54
55 AD33 GND 56
57 +5V (Vio) AD32 58
59 Reserved Reserved 60
61 Reserved GND 62
63 GND Reserved 64
Pin Assignment Pin
1 PMC2_1 (P2-D1) PMC2_2 (P2-Z1) 2
3 PMC2_3 (P2-D2) PMC2_4 (P2-D3) 4
5 PMC2_5 (P2-Z3) PMC2_6 (P2-D4) 6
7 PMC2_7 (P2-D5) PMC2_8 (P2-Z5) 8
9 PMC2_9 (P2-D6) PMC2_10 (P2-D7) 10
11 PMC2_11 (P2-Z7) PMC2_12 (P2-D8) 12
13 PMC2_13 (P2-D9) PMC2_14 (P2-Z9) 14
15 PMC2_15 (P2-D10 PMC2_16 (P2-D11) 16
Pin Assignment Pin
