About this Manual
16
About this Manual
Chapter 1, Hardware Preparation and Installation , provides a description of the MVME5100 and
its main integrated PMC and IPMC boards. The remainder of the chapter includes an
explanation of the installation procedure, including preparation and jumper setting
information.
MVME7616E-001 Transition module: Two DB-9 async serial port
connectors, two HD-26 sync/async serial port
connectors, one HD-36 parallel port connector, and one
RJ-45 10/100 Ethernet connector; includes 3-row DIN P2
adapter module and cable (for 8-bit SCSI).
MVME7616E-011 Transition module: Two DB-9 async serial port
connectors, two HD-26 sync/async serial port
connectors, one HD-36 parallel port connector, and one
RJ-45 10/100 Ethernet connector; includes 5-row DIN P2
adapter module and cable (for 16-bit SCSI); requires
backplane with 5-row DIN connectors.
SIM232DCE5E or DTE EIA-232 DCE or DTE Serial Interface Module.
Related Products
PMCSPAN26E-002 Primary PMCSPAN with original VME Scanbe ejector
handles.
PMCSPAN26E-010 Secondary PMCSAN with original VME Scanbe ejector
handles.
RAM5005E-006 Stackable (top) 256MB ECC SDRAM mezzanine.
RAM5005E-016 Stackable (bottom) 256MB ECC SDRAM mezzanine.
RAM5005E-010 Stackable (top) 512MB ECC SDRAM mezzanine.
RAM5005E-020 Stackable (bottom) 512MB ECC SDRAM mezzanine.
RAM5006E-005 Stackable (top) 128MB ECC DRAM
RAM5006E-015 Stackable (bottom) 128MB ECC DRAM
RAM5006E-006 Stackable (top) 256MB ECC DRAM
RAM5006E-016 Stackable (bottom) 256MB ECC DRAM
RAM5006E-010 Stackable (top) 512MB ECC DRAM
RAM5006E-020 Stackable (bottom) 512MB ECC DRAM
