3 secondary pmcspan – Artesyn MVME51005E SBC Installation and Use (July 2014) User Manual
Page 30
Hardware Preparation and Installation
MVME51005E Single Board Computer Installation and Use (6806800A38D)
32
1.3.3
Secondary PMCspan
The PMCspan16E-010 PCI expansion module mounts on top of a PMCspan16E-002 PCI
expansion module. To install a PMCspan-010 on your MVME5100, perform the following steps
while referring to the figure on the next page:
Dangerous voltages, capable of causing death, are present in this equipment. Use extreme
caution when handling, testing and adjusting.
Inserting or removing modules with power applied may result in damage to module
components. Avoid touching areas of integrated circuitry, static discharge can damage
these circuits.
