PPCBug Firmware
MVME51005E Single Board Computer Installation and Use (6806800A38D) 66
Note:
1. You may enter command names in either uppercase or lowercase.
2. Some diagnostics depend on restart defaults that are set up only in a particular restart
mode. Refer to the documentation on a particular diagnostic for the correct mode.
3. Test Sets marked with an asterisk (*) are not available on the MVME5100 (unless an
IPMC712 or IPMC761 is mounted). The ISABRDGE test is only performed if an IPMC761 is
mounted on the MVME5100. If the MVME5100 is operating in PMC mode (IPMC761 is not
mounted), then the test suite is bypassed.
Table 3-2 Diagnostic Test Groups
Test Group Description
EPIC EPIC Timers Test
PHB PCI Bridge Revision Test
RAM RAM Tests (various)
HOSTDMA DMA Transfer Test
RTC MK48Txx Real Time Clock Tests
UART Serial Input/Output Tests (Register, IRQ, Baud, & Loopback)
Z8536 Z8536 Counter/Timer Tests*
SCC Serial Communications Controller (Z85C230) Tests*
PAR8730x Parallel Interface (PC8730x) Test*
KBD8730x PC8730x Keyboard/Mouse Tests*
ISABRDGE PCI/ISA Bridge Tests (Register Access & IRQ)
VME3 VME3 Tests (Register Read & Register Walking Bit)
DEC DEC21x43 Ethernet Controller Tests
CL1283 Parallel Interface (CL1283) Tests*
