Table c-2, Thermal analysis – Artesyn MVME51005E SBC Installation and Use (July 2014) User Manual
Page 138
Thermal Analysis
MVME51005E Single Board Computer Installation and Use (6806800A38D)
140
U9
ECC DRAM (NEC
D4564841G5)
70
Ambient
U4
Intel 82559ER
85
Case
U5
Intel 82559ER
85
Case
U3
Universe 2
125
Junction
U29
L2 cache 512K
(MCM69P7377P)
70
Ambient
U30
L2 cache 512K
(MCM69P7377P)
70
Ambient
U31
MPC952
125
Junction
U32
MPC972
125
Junction
U21
ECC DRAM (NEC
D4564841G5)
70
Ambient
U16
ECC DRAM (NEC
D4564841G5)
70
Ambient
U19
PPC7400@400
MHz (Max)
105
Junction
U53
Pulse H0009.2
9942-C
85
Ambient
1 maximum temperature for reliable operation specified by the component manufacturer.
Table C-2 Thermally Significant Components on the IPMC761 Module
Reference
Designator?
Generic Description
Maximum Allowable
Component
Temperature (degrees
C) 1
Measurement Location
U6
Super I/O National
Semiconductor
70
Ambient
U3
Zilog (Z0853606 VSC)
70
Ambient
Table C-1 Thermally Significant Components on the MVME5100 Single Board Computer
Reference
Designator?
Generic
Description
Maximum Allowable
Component Temperature
(degrees C) 1
Measurement Location
