Hardware Preparation and Installation
MVME51005E Single Board Computer Installation and Use (6806800A38D) 31
1.3.2 Primary PMCspan
To install a PMCspan16E-002 PCI expansion module on your MVME5100, perform the
following steps while referring to the figure on the next page:
Note: This procedure assumes that you have read the user’s manual that was furnished with
your PMCspan and that you have installed the selected PMC modules on to your PMCspan
according to the instructions provided in the PMCspan and PMC manuals.
1. Attach an ESD strap to your wrist. Attach the other end of the ESD strap to an electrical
ground. Note that the system chassis may not be grounded if it is unplugged. The ESD
strap must be secured to your wrist and to ground throughout the procedure.
2. Perform an operating system shutdown. Turn the AC or DC power off and remove the AC
cord or DC power lines from the system. Remove chassis or system cover(s) as necessary
for access to the VME modules.
3. If the MVME5100 has already been installed in a VMEbus card slot, carefully remove it as
shown in Figure 1-3 and place it with connectors P1 and P2 facing you.
4. Attach the four standoffs to the MVME5100. For each standoff:
 Insert the threaded end into the standoff hole at each corner of the MVME5100.
 Thread the locking nuts into the standoff tips and tighten.
5. Place the PMCspan on top of the MVME5100. Align the mounting holes in each corner to
the standoffs and align PMCspan connector P4 with MVME5100 connector J25.
Dangerous voltages, capable of causing death, are present in this equipment. Use extreme
caution when handling, testing and adjusting.
Inserting or removing modules with power applied may result in damage to module
components. Avoid touching areas of integrated circuitry, static discharge can damage
these circuits.
