Specifications
460 FTB-8500 Series and FTB-8120NGE/8130NGE
Ethernet Electrical Interfaces
Ethernet Electrical Interfaces
For IQS-8510B:
For IQS-8120NGE/IQS-8130NGE and IQS-8525/IQS-8535:
ELECTRICAL INTERFACES
Electrical interfaces Two ports 10/100BaseT half/full duplex, 1000BaseT a full duplex.
Straight/crossover cable selection.
10Base-T 100Base-T 1000Base-T
Tx bit rate 10 Mbit/s 125 Mbit/s 1 Gbit/s
Tx accuracy (ppm) ±100 ±100 ±100
Rx bit rate 10 Mbit/s 125 Mbit/s 1 Gbit/s
Rx measurement accuracy (ppm) ±4.6 ±4.6 ±4.6
Duplex mode Half and full duplex Half and full duplex Full duplex
Jitter compliance IEEE 802.3 IEEE 802.3 IEEE 802.3
Connector RJ-45 RJ-45 RJ-45
Maximum reach (m) 100 100 100
Note
a. Available as a software option.
ELECTRICAL INTERFACES
10Base-T 100Base-T 1000Base-T
Tx bit rate 10 Mbit/s 125 Mbit/s 1 Gbit/s
Tx accuracy (ppm) ±100 ±100 ±100
Rx bit rate 10 Mbit/s 125 Mbit/s 1 Gbit/s
Rx measurement accuracy (ppm) ±4.6 ±4.6 ±4.6
Duplex mode Half and full duplex Half and full duplex Full duplex
Jitter compliance IEEE 802.3 IEEE 802.3 IEEE 802.3
Connector RJ-45 RJ-45 RJ-45
Maximum reach (m) 100 100 100
