268 FTB-8500 Series and FTB-8120NGE/8130NGE
Overview
Column Description

Join Status: Indicates the join status for each multicast stream only.
The join status icons become grayed out when the test is stopped.

Stream Name: Indicates the configured name associated to an IP
address in the Alias Map. See Alias Map on page 279 for more details.

Dest IP Address: Indicates the IP address associated to the monitored
stream.

Port: Indicates the UDP port number associated to the monitored
stream.
Icon Status Description
Joining The joining state is reported following a join
request until the desired stream is received or
the join timeout expires.
Joined The joined state is reported when the desired
stream is received before the join timeout
expires.
Failed The failed state is reported when the stream
remains undetected within the join timeout. See
Join Timeout on page 293. Upon failure, a leave
request is issued on that stream.
Idle The idle state is reported initially for all multicast
streams that are not member of a group and
doesn’t have the failed status.
