Physical Interfaces and LEDs
12 FTB-8500 Series and FTB-8120NGE/8130NGE
IQS-8510B Model
Note: The optical 100 Mbps Ethernet ports and Fibre Channel 1x and 2x ports are
available through software options. Refer to Software Options on page 380
for more information.
Electrical 10/100/1000 Mbps Ethernet
The IQS-8510B module provides two electrical ports for 10Base-T, or
100Base-TX. The IQS-8510B-1 and IQS-8510B-2 options add respectively
1000Base-T testing capability on one or both ports.
Port connector type is RJ-45 for category 5 unshielded twisted pair (UTP)
connection.
Note: Refer to Specifications on page 455 for cable specifications.

Connect the 10/100/1000 electrical signal to be tested to the port
10/100/1000 #1 or 10/100/1000 #2.
Note: Port #1 is the port enabled with the IQS-8510B-1 module for 1000Base-T
testing.

LEDs
LED Status Description
LINK/ACT
(Green) On Ethernet link up.
Off Ethernet link down.
Flashing TX/RX activity.
DUPLEX
(Yellow) On Full Duplex mode.
Off Half Duplex mode.
Flashing Collisions are detected.
