Ethernet and Fibre Channel Application 161
9 Traffic Analyzer Tabs
Note: The available Traffic Analyzer tabs depend on which test path is activated.
Test Tab Page
Available with
Frame
Analyzer BERT
RFC
2544
Smart
Loopback
TCP
Throughput
a
a. Only available with IQS-8510B
Ethernet Ethernet TX 162 X
Ethernet RX 165 X X X X X
Ethernet Statistics 168 X X X X X
PBB-TE 170 X
Higher Layers 172 X X X X X
Flow Control 174 X X X
Traffic Filters 177 X
Traffic Filter
Configuration 182 X
Traffic Filter Stats 184 X
Capture 186 X
Graph 191 X
Performance
Monitoring (PM) 363 X
b
b. For IQS-8510B, IQS-8120NGE/IQS-8130NGE, and IQS-8525/IQS-8535: Available with Framed Layer 2, and
Frame Layer 1 with xPAT pattern (Ethernet 1000Mbps and Fibre Channel interface only).
For IQS-8510G: Available for Framed Layer 2 with LAN transceiver mode.
Fibre
Channel
c
c. Not available with IQS-8510G
.
FC TX 192 X
FC RX 195 X
FC Latency 197 X
FC Statistics 199 X
Performance
Monitoring (PM) 363 X
