Physical Interfaces and LEDs
Ethernet and Fibre Channel Application 19
IQS-8525 and IQS-8535 Models
The following table shows the list of available ports as well as a description
and signals supported for each model.
Electrical 10/100/1000 Mbps Ethernet
The IQS-8525/IQS-8535 module provides one electrical port for 10Base-T,
100Base-T, or 1000Base-T.
Port connector type is RJ-45 for category 5 unshielded twisted pair (UTP)
connection.
Note: Refer to Specifications on page 455 for cable specifications.

Connect the 10/100/1000 electrical signal to be tested to the port
ETHERNET 10/100/1000.
Port labelled Description Supported signal(s) Model
FC 1x/2x/4x
ETHERNET
100M/1G
Optical IN/OUT port small
form pluggable (SFP)
Fibre Channel 1x, 2x, and 4x
Ethernet 100 Mbps and 1 Gbps
IQS-8525
IQS-8535
FC 10x
ETHERNET 10G
Optical IN/OUT port small
form pluggable (XFP)
Fibre Channel 10x
Ethernet 10 Gbps
IQS-8535
Ethernet
10/100/1000M
Electrical Ethernet port
RJ-45
10/100/1000 Mbps (electrical) IQS-8525
IQS-8535
EXT CLK Electrical port BNC DS1/1.5M/E1/2M signal for
external clock synchronization.
IQS-8535
REF OUT Reference output port SMA IQS-8535
