Multi-meter Tests

Copper, VDSL2, ADSL2+ and IP Triple-Play Test Set

85

Multi-meter

Metallic Insulation

The Metallic Insulation tab allows you
to run a resistance test over a period of
time to look for high-resistive faults.
This method may also reveal poor
wire.

Connection defines the type of cable
connection to be tested, as specified in
Regional Settings.

To start/stop the test:
1.
Press the up/down arrow keys to highlight the desired test parameter.

2. Press

to open the list.

3. Press the up/down arrow keys to highlight the desired value, then press

to select it.

4. Press

to start/stop the test.

Test results are displayed on the screen as they are completed.
