Getting Started with DSL and Ethernet Testing
Copper, VDSL2, ADSL2+ and IP Triple-Play Test Set 147
Saving Results
Saving Results
You can save any of your results after running and viewing a test performed
with the AXS-200/635i, in either text or graphical format. Each DSL/IP test
includes a Save Results tab to do so.
Press the F1, F2, or F3 key to view this tab, or use the function
arrow keys on either side of the F1 and F3 keys to access it.
Save Result
The Save Result tab allows you to save your test results to a file or to an
HTML report.
Each entry on the pane is described
below:
³
Save as Type lists the following
formats to save your test results:
³
AXS200 format is a binary file
format with ext *.dat. This
format can be opened only on
an AXS200 unit. The Available
Graphs list box will be
unavailable in this case.
³
*.csv saves only graphical results.Textual results must be formatted
as a comma-separated values table for easy importation to Excel.
Results are saved to USB.
³
*.gif stands for graphics interchange format and is one of the most
common file formats for graphic images on the World Wide Web.
Results are saved to USB.
³
*.bmp saves graphical results in a bitmap file format. Results are
saved to USB.
³
*.xml saves your data in a common language format to share on
the Web. Results are saved to USB.
