Navigating through the AXS-200/635i
Navigating through the AXS-200/635i
Use the following general instructions to navigate through the AXS-200/635i
menus and panes:
³
To navigate through the menu
items use the arrow keys or press
the corresponding test number on
the keypad.
³
To confirm a choice or open a
menu item press
.
³
Most manual tests
automatically run when they
are selected from the menu.
³
The rotating hour glass in the title bar indicates when a test is
running.
Note: For Fault Isolation Tools, the unit
checks for an active circuit at the
beginning of every manual and auto
test.
³
To start/stop a test, press .
³
To view the contents of the panes
or tabs, use the F1, F2, and
F3 keys. To view any available
additional tabs use the function arrow keys on either side of the F1 and
F3 keys.
³
To cancel an action or return to the previous item or pane, press .
³
To return to the home pane, press .
