Technical Specifications
Copper, VDSL2, ADSL2+ and IP Triple-Play Test Set 259
GENERAL SPECIFICATIONS
Module size (H x W x D) 283 mm x 125 mm x 92 mm (11 1 / 8 in x 4 15 / 16 in x 3 5 / 8 in)
Module weight (with battery) 1.3 kg (2.8 lb)
Temperature
operating 0 °C to 50 °C (32 °F to 122 °F)
storage —20 °C to 60 °C (—4 °F to 140 °F)
Humidity 5 % to 95 % relative, non-condensing
Power supply
input 100-240 VAC at 1.8 A, 50 Hz to 60 Hz
output 18-24 VDC at 3.33 A to 2.50 A, 60 W
Battery Internal rechargeable Li-Ion battery, with battery state indication
Test connections Five-color banana connector for T, R, G, T1, R1
RJ-45 for ADSL2+ and Ethernet 10/100 WAN
RJ-45 for Ethernet 10/100 LAN
Differential voltage protection 125 VRMS or 400 VDC max
Common mode voltage protection 1000 VRMS
Self-test Routine on power-up
Voltage detection > 20 V will trigger alarm message
Results storage 128 MB
Languages English, French, German, Spanish, Chinese (Simplified)
Specifications based on 24 AWG (0.5 PE mm) cabling and subject to change without notice.
STANDARD ACCESSORIES
Hand strap, Certificate of Compliance
ACC-RJTC: RJ-45 to telco clip (test cable), or ACC-RJMM: RJ-45 to 4 mm plugs with crocodile clips (test cable)
ACC-RJRJ: RJ-45 Ethernet cable
ACC-5COLR: Five-color 4 mm banana plugs terminated with telco clips, or ACC-5COLR4MM: Five-color 4 mm banana plugs terminated with 4 mm plugs with crocodile clips
ACC-STRP: RFL strap
