EXFO VDSL2 - Manual (Page 101)

Multi-meter Tests
Copper, VDSL2, ADSL2+ and IP Triple-Play Test Set 93
Resistive Balance
To set parameter values and start/stop the test:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press to select the value.
3. Press the left arrow key to erase the existing value, and then use the
alphanumeric keypad to enter a value. To cancel the entry, press .
4. Press to accept the value.
5. Select other parameters as required.
6. Press to start/stop the test.
Resistive Balance
The Resistive Balance test measures
and compares the resistance of each
leg. This test requires the T/R/G
connections to be shorted together at
the far end of the line under test.
