Connection Setup for DSL/IP Triple-Play Verification Tests
160
AXS-200/635i
Setup Line Connection
³
DNS2 is the address of the secondary domain name server to be used
by the unit. If DNS is unavailable, enter 0.0.0.0.
³
Local MAC Address is the internal MAC address of the unit: either
AXS200 or User Defined.
³
MAC Address is a specific MAC address, maximum 17 characters, if
you select User Defined for the previous parameter.
When the AccessMode selection is set
to Routed PPPoE, the available
parameters are the following:
³
Obtain IP is either Dynamic
where the access concentrator or
broadband remote access server
assigns a temporary IP address to
the unit, or Static where you enter
the IP address of the unit.
³
Static IP is the address of the current location assigned by the service
provider. This entry is unavailable if Obtain IP is set to Dynamic.
³
Login Name is your user ID.
³
Password is your user password.
Note: WAN IP setup is not required when Access Mode is set to Bridged. The line
encapsulation setting defines the parameters required.
