PCB Layout Guidelines
Printed circuit board (PCB) layout for a Router 5000 or FT Router 5000 is similar
to layout for a Neuron 5000 Processor or FT 5000 Smart Transceiver, and should
include the following general features:
• Star-Ground Configuration: Arrange the various blocks of the device that
directly interface with off-board connections (the network, any external
I/O, and the power supply cable) so that they are together along one edge
of the PCB.
• ESD Keepout Area: Consider the area around the network connection
traces and components as “ESD Hot”. The PCB layout should be
designed so that substantial ESD hits from the network discharge
directly to the star-ground center point.
• Clamp Diodes: For transceivers that use differential receive signals (such
as the TP/XF-1250 transceiver) use four diodes to clamp the transceiver’s
differential receive signals to ground during ESD and surge transients.
For the FT Router 5000, use diodes to clamp the FT Router 5000 side of
the FT-X3 transformer between V
DD33
and ground.
• Ground Return for a Series 5000 router: A Router 5000 has internal
protection circuitry built into its CP[4..0] pins, and an FT Router 5000
has internal protection circuitry built into its NETP and NETN pins.
When an ESD or surge transient comes in from the network, the portion
of the transient that makes it to the Series 5000 router is clamped to the
chip’s V
DD33
power pins and ground pins. Be sure to provide a short and
wide ground path from the Series 5000 router back to the center of the
star ground.
• Ground Planes: As ground is routed from the center of the star out to the
function blocks on the board; planes or very wide traces should be used to
lower the inductance (and therefore the impedance) of the ground
distribution system.
• V
DD33
Decoupling Capacitors: A good rule of thumb is to provide at least
one V
DD33
decoupling capacitor to ground for each V
DD33
power pin on an
IC in the design. For SMT devices like a Series 5000 router, each
decoupling capacitor should be placed on the top layer with the chip, and
placed as close as possible to the chip to minimize the length of V
DD33
trace between the capacitor and the chip’s V
DD33
pad.
Router 5000
Figure 42 shows a portion of the top layer of a 4-layer PCB layout for the Router
5000 half-router for a TP/XF-1250 transceiver, including the differential driver
circuit, and the comparator circuit, and the other building blocks of a PCB design.
The figure shows a rectangle for the placement of the TPT/XF-1250 transceiver
PCB, which is mounted above the main board.
See the Connecting a Neuron 5000 Processor to an External Transceiver
Engineering Bulletin for more information about PCB layout considerations for
connecting external transceivers to Neuron 5000 Processors, including the Router
5000. See Chapters 3 and 4 of the Series 5000 Chip Data Book for additional
