reinitialized. This reinitialization allows a network services tool to change

parameters, such as the number of priority slots, without the new values’ being

overwritten by the RTR-10 firmware.

Table 7. RTR-10 Router Transceiver IDs

ID

Name

Media

Bit Rate

(bps)

Input

Clock

01 (0x01)

TP/XF-78

Transformer-isolated twisted pair

78k

10 MHz

03 (0x03)

TP/XF-1250

Transformer-isolated twisted pair

1.25M

10 MHz

04 (0x04)

TP/FT-10

Free Topology and Link Power

78k

10 MHz

05 (0x05)

TP/RS485-39

EIA-485 twisted pair

39k

10 MHz

07 (0x07)

RF-10

Radio Frequency (49 MHz)

4.9k

5 MHz

09 (0x09)

PL-10

Power Line spread-spectrum

10k

10 MHz

10 (0x0A) TP/RS485-625 EIA-485 twisted pair

625k

10 MHz

11 (0x0B) TP/RS485-125 EIA-485 twisted pair

1.25M

10 MHz

12 (0x0C) TP/RS485-78

EIA-485 twisted pair

78k

10 MHz

16 (0x10)

PL-20C

Power Line C-Band

5.4k

10 MHz

17 (0x11)

PL-20N

Power Line C-Band

5.4k

10 MHz

18 (0x12)

PL-30

Power Line A-Band

2.7k

10 MHz

24 (0x18)

FO-10

Direct Connect

1.25M

10 MHz

27 (0x1B) DC-78

Direct Connect

78k

10 MHz

28 (0x1C) DC-625

Direct Connect

625k

10 MHz

29 (0x1D) DC-1250

Direct Connect

1.25M

10 MHz

30 (0x1E) Custom

Custom

Custom

Custom

Notes:

Type 07 (0x07) can be used for Side B only.

PL-20C channels use the CENELEC protocol; PL-20N channels do not use the

CENELEC protocol.

Type 30 (0x1E) can be used for any transceiver type; the communications port is

initially defined as all inputs to prevent circuit conflicts. The side using type 30

(0x1E) must be reprogrammed through the other router side.
