L

ON

W

ORKS

router. Although not shown in the figure, you can place a Router

5000 half router (with its transceiver module) and FT Router 5000 half router on

the same motherboard to create a L

ON

W

ORKS

router.

A complete L

ON

W

ORKS

router can be packaged in an enclosure to meet unique

form factor and environmental requirements. Depending on the application, the

package could contain a single router sub-assembly, or could include other

application-specific hardware. Multiple routers can be packaged together for

some applications, such as a backbone connecting multiple channels.
Unlike an RTR-10 router, you store the L

ON

W

ORKS

transceiver parameters for

each Router 5000 or FT Router 5000 half router in external EEPROM, thus

allowing you to define the appropriate transceiver type for each side.

Comparing the RTR-10, Router 5000, and FT Router
5000

Table 2 lists some of the major characteristics of the three router products

described in this manual.

Table 2. Comparing the RTR-10, Router 5000, and FT Router 5000

Parameter

RTR-10

Router 5000

FT Router 5000

Package

Integrated module with

both A side and B side

7mm x 7mm QFN chip 7mm x 7mm QFN chip

Voltage

5 V

3.3 V

3.3 V

Clock rate

10 MHz A side
≤10 MHz B side

5, 10, 20, or 40 MHz

system clock

(10 MHz crystal)

5, 10, 20, or 40 MHz

system clock

(10 MHz crystal)

Router Buffers 1408 bytes

25 KB

25 KB

Transceivers

Any

TP/FT-10
TP-RS485
TP/XF-78
TP/XF-1250
LPT-11 Link-power
Other (contact Echelon

Support)

TP/FT-10
(requires an FT-X3

Communications

Transformer)

The main difference between the Router 5000 and the FT Router 5000 is their

transceiver support. The FT Router 5000 supports only the TP/FT-10 channel,

but because the transceiver is integrated into the chip, you do not need to use an

FTT-10A Free Topology Transceiver (and associated circuitry to accommodate the

different voltage standards between the half router and transceiver).

8

Introduction to LONWORKS Routers
