the destination address is then checked to determine whether the message

should be forwarded or dropped. The forwarding flags are all cleared whenever

the router is reset, so the learning process restarts after a reset.
The forwarding flag for a given subnet should never be cleared on both sides of a

router. However, the flag can be cleared on both sides if a device is moved from

one side of a router to the other side. For example, if subnet 1 is located on side

A of a router, the router will learn subnet 1’s location as soon as it receives a

message generated by any device in subnet 1. If any subnet 1 device is moved to

side B without reinstalling it, the router will learn that subnet 1 is also on side B,

and will stop forwarding subnet 1 messages to side A. The router detects this

error and logs it, as described in Chapter 7, Network Management Messages.

Router receives

message packet

Is message addressed

to either of the router’s

domains?

Is message domain

length zero, source

subnet zero, addressed

as broadcast?

Drop packet

Is message source

subnet zero?

Is message domain

length zero, addressed

as broadcast?

Clear subnet fwd flag

Set message source subnet

= router subnet

Substitute one or both

domains from the router,

source subnet = our

subnet, dest subnet zero

Forward one or two

packets

No

Yes

Yes

Yes

No

Yes

No

No

Page 2

* Applies to

learning

router only

Figure 4. Configured and Learning Router Forwarding Rules, Part 1
