Table 11. Service LED Behavior during Different States

Device State

State Code

Service LED

Applicationless and

Unconfigured

3

On

Unconfigured (but with

an Application)

2

Flashing

Configured, Hard Offline 6

Off

Configured

4

Off

Defective External

Memory

On

The SVC~ pin is active low, and the service pin message is sent once per SVC~

pin transition. The service pin message goes into the next available non-priority

output network buffer.
Typical applications do not require debounce conditioning of a momentary

pushbutton attached to the SVC~ pin. The software response time associated

with this input is long enough to effectively provide a software debounce for

switches with a contact bounce settling time as long as 20 milliseconds.
If your router uses a Series 3100 half-router for one of its sides, you can connect

the Series 5000 router’s SVC~ pin to the Series 3100 SERVICE~ pin, as shown

in Figure 19, using the Series 3100 Smart Transceiver’s +5 V power supply for

the Service switch, LEDs and diode clamps.
See the Series 5000 Chip Data Book for more information about the SVC~ pin for

a Series 5000 chip, including the Router 5000 and FT Router 5000.

42

LONWORKS Router Electrical Interfaces
