Parameter

TP/XF-78

TP/XF-1250

TP/FT-10

TP/RS485-39

Alternate Rate

N/A

N/A

N/A

N/A

Wakeup Pin Direction

N/A

N/A

N/A

N/A

XCVR Controls Preamble N/A

N/A

N/A

N/A

General Purpose Data

N/A

N/A

N/A

N/A

Allow Node Override

N/A

N/A

N/A

N/A

Receive Start Delay

2.9 bits

14.0 bits

9.0 bits

2.0 bits

Receive End Delay

0.0 bits

0.0 bits

0.0 bits

0.0 bits

Indeterminate Time

24.0 bits

25.0 bits

24.0 bits

4.0 bits

Min Interpacket Time

0.0 bits

0.0 bits

0.0 bits

0.0 bits

Turnaround Time

0 µsec

0 µsec

0 µsec

0 µsec

Missed Preamble

1.0 bits

4.0 bits

4.0 bits

1.0 bits

Preamble Length

N/A

N/A

N/A

N/A

Use Raw Data

No

No

No

No

Table 24. Communications Parameters, Part 2

Parameter

RF-10

PL-10

PL-20C

PL-20N

Transceiver ID

7 (0x07)

9 (0x09)

16 (0x10)

17 (0x11)

Media

49 MHz Radio

Frequency

Power Line

Power Line

Power Line

Neuron Chip to

Transceiver Interface

Single Ended Special

Purpose

Special

Purpose

Special

Purpose

Interface Bit Rate

4.9 kbps

625 kbps

156.3 kbps

156.3 kbps

Input Clock

5 MHz

10 MHz

10 MHz

10 MHz

Minimum Clock

Configurable;

default = 5

MHz

Configurable;

default = 5

MHz

Configurable;

default = 1.25

MHz

Configurable;

default = 1.25

MHz

L

ON

W

ORKS

Router User’s Guide

111
