USER’S GUIDE
48 CyberSWITCH
S
YSTEM
M
ODULES
T
HE
CSX1200-E11-MOD
The CSX1200-E11-MOD is an internal 11 port Ethernet hub option card for the CSX1200 family. The
CSX1200-E11-MOD is available for both the BRI (CSX1201, CSX1204) and PRI (CSX1223) models.
The CSX1223 is shown below.
The internal hub addition provides affordable LAN device connectivity. The backplane has eleven
RJ-45 modular jacks. Ten of those jacks may be used to connect to PCs. One jack is used to provide
the internal hub with LAN connectivity to the CSX1200 device (see following graphic).
CONSOLE
10Base-T
AUI
SLOT 1
AIS LOF
RAI LOS
SLOT 2
S
L
O
T
4
S
L
O
T
3
6 5 4 3 2 1
9 8 7
11 10
CSX1223 with CSX1200-E11-MOD
B25 B27
B26 B28
WORKGROUP REMOTE ACCESS SWITCH
B29
E1 ONLY
B-CHANNELS
LAN
10BASE-T
RX
TX
SERVICE
B31
B30 L1
B21 B23
B22 B24
B17 B19
B18 B20
B13 B15
B14 B16
E1
D
T1
D
B9
B11
B10 B12
B5
B7
B6
B8
B1
B3
B2
B4
POWER
