Workgroup Remote Access Switch 293
C ONFIGURING IPX
IPX-Specific Information for Devices
4. Press 1 to add a device.
5. Enter the device’s name and press . You should provide ISDN and Authentication
information first.
6. Select IPX. A screen similar to the following will be displayed:
7. Enable IPX routing. Select IPX Routing and follow on-screen instructions.
8. Enable make calls feature. Select Make calls for IPX data and follow on-screen instructions only
if the CyberSWITCH is to dial-out to remote1.
9. Although IPXWAN Protocol appears on the menu, the feature is not yet completely functional.
10. Select Routing Protocol. A menu similar to the following will be displayed:
11. Select routing protocol. When you select Triggered RIP/SAP, you will need to identify the WAN
peer type as either active or passive. An active peer receives broadcasts at all times; a passive
peer receives broadcasts only when a connection is up.
12. Select Spoofing Options. Make changes to default spoofing setup, if desired, through the
following menu:
a. Press 1 to configure IPX watchdog spoofing. The following menu will be displayed:
Device IPX Configuration Menu: (Device = "remote1")
1) IPX Routing DISABLED
2) Make calls for IPX data DISABLED
3) IPXWAN Protocol DISABLED
4) Routing Protocol NONE
5) Spoofing Options
Select function from above or for previous menu:
IPX Device Routing Protocol Menu:
1) None
2) RIP/SAP
3) Triggered RIP/SAP
Enter selection or press for previous menu [default=None}: 3
1) ACTIVE
2) PASSIVE
Triggered RIP/SAP WAN Peer type [default=ACTIVE]: 1
IPX Device Spoofing Menu:
1) IPX Watchdog Spoofing
2) SPX Watchdog Spoofing
3) Serialization Packet Handling
4) Message Packet Handling
Select function from above or for previous menu: 1
