C
ONFIGURING
A
LTERNATE
A
CCESSES
O
VERVIEW
An access defines the connection details the CyberSWITCH uses to reach the network. The default
access is ISDN access, a switched-network access. Configurable accesses are required for dedicated
network connections, for packet-switched network connections including X.25 and frame relay
connections. Refer to the information below for the alternate access you wish to add.
D
EDICATED
A
CCESSES
C
ONFIGURING
A
D
EDICATED
A
CCESS
U
SING
CFGEDIT
1.
Select Access from the Physical Resources menu, then follow the onscreen instructions to add a
dedicated access.
2.
Select the line Id of the line you will use for this access.
3.
For BRI and PRI lines: select the bearer channels the access will use.
4.
Select the line protocol. In almost all cases, select PPP. Select HDLC only if you are connecting
to a device that uses HDLC over a dedicated access.
5.
Enter the device name tied to this access (optional for accesses using PPP protocol, mandatory
for accesses using HDLC protocol).
Note:
Device authentication must be enabled for dedicated accesses to properly identify the
remote device and provide switched backup and overflow to that device. Remote devices
using a dedicated connection must use PPP for device authentication. Authentication
configuration is described in
.
U
SING
M
ANAGE
M
ODE
C
OMMANDS
dedacc
Displays previously configured dedicated accesses.
D
EDICATED
A
CCESS
C
ONFIGURATION
E
LEMENTS
L
INES
The line that will be used for the dedicated access. A dedicated access can be defined on either a
BRI or a PRI line.
B
EARER
C
HANNELS
For BRI and PRI lines only. Also referred to as B channels. B channels can carry voice or data in
either direction.
