HYDROSTATIC CONTROLS AND CONSOLE
MODELS 931019, 22, 25 & 26
USED ON THE FOLLOWING MODELS
Model No.
931019
931022
931025
931026
Serial No.
005500 and up
002500 and up
000600 and up
001000 and up
REF.
NO. PART
N0.
DESCRIPTION NO. REQ'O
REF.
NO. PART
NO.
DESCRIPTION NO. REQ'O
1 030373 Control Box 1 41 065039 Locknut, Hex, 3/8" 1
2 055024 Bushing 2 42 065100 Nut, Hex Jam, 5/16" 4
3 030390 Shift Rod 1 43 064123 Washer, Flat, 5/16" 2
4 075049 Handle 1 44 062029 Bolt, Carriage, 3/8" x 1" 1
5 031258 Arm 1 45 059152 Cap Screw, HH, 3/8" x 2-1/2" Gr. 5 1
6 064028 Washer, Spacer, 7f16" ID x 1-118" 00 46 059069 Cap Screw, HH, 5/16" x 1-1/4", Gr. 5 2
X 3/16" 2 47 063003 Lockwasher, 5/16" 2
7 055089 Bushing 1 48 065015 Nut, Hex, 5/16" 2
8 031162 Washer, Special 1 49 061064 Screw, Machine Fillister Hd. 5/16" x 2-3/4" 2
9 069100 Cable, 24-7/8" Long 1 53 074045 Tapping Screw 8
10 030392 Lever 1 56 063024 Lockwasher 8
11 030394 Strap 1 58 030391 Shift Shaft 1
12 075066 Grommet 1 61 031100 Lock Pin Guide 1
13 030395 Spacer 2 62 031099 Pivot Plate 1
14 030393 R.H. Friction Angle 1 63 031098 Pin 1
15 031566 L.H. Friction Angle 1 64 064128 Washer, Special, 11/32" ID x 1-3/8" OD
16 059023 Cap Screw, HH, 3/8" x 3/4" 1 X 14 Ga. 1
17 083125 Spring, 1-1/2" Long 2 65 083121 Spring 1
18 030401 Shift Rod 1 66 031097 Pin 1
23 031024 Brace 1 67 056075 "D" Ring 1
26 063021 Lockwasher, 3/8" 5 68 067004 Pin, Cotter, 1/8" X 1" 1
27 064008 Washer, Flat, 3/8" 4 70 031724 Shift Lock 1
28 065018 Nut, Hex, 3/8" 5 71 067034 Cotter Pin, 3/32" X 1/2" 2
29 059135 Cap Screw, 5/16-18 x 3/4" Gr. 5 1 72 083149 Spring 1
30 065124 Locknut, Hex, 5/16" 3 73 069110 Clamp 1
31 058003 Roll Pin, 3/16" X 1-1/4" 2 74 059004 Screw, 3/8-16 X 1" 1
34 062013 Carriage Bolt, 3/8-16 x 1" 3 76 . 063021 Lockwasher, 3/8" SAE, Std. Regular 1
36 031167 Gasket 1 77 065018 Nut, 3/8-16 1
37 083120 Spring 1 78 010353 Zerk Fitting 1
38 058005 Pin, Spring 3/16" X 7/8" 2 79 064057 Washer, 21/64" ID x .625 DD x .062 2
39 064003 Washer, Flat, 1/2" 5 80 059140 Capscrew, 5/16-18 x 2" 2
40 064043 Washer, Flat, 3/8" 2 81 064039 Washer, .630 ID x 1.005 OD x .062 1
82 064057 Washer 6
83
