HYDROSTATIC CONTROLS AND CONSOLE
MODELS 931004-10 & 15-18
REF.
NO.
PART
NO.
DESCRIPTION
NO. REQ'D
REF.
NO.
PART
NO.
DESCRIPTION
NO. REQ'D
1
031160
CONTROL BOX
1
41
065098
LOCKNUT, Hex, 3/8"
1
2
055024
BUSHING
2
42
065100
NUT, Hex Jam, 5/16"
4
3
031064
SHIFT ROO
1
43
064123
WASHER, Flat, 5/16"
8
4
075049
HANDLE
1
44
062029
BOLT, Carriage, 3/8 x 1
1
5
031258
ARM
1
45
059152
CAPSCREW, HH, 3/8
X
2-1/2 Grade 5
1
6
064028
WASHER, Spacer
2
46
059069
CAPSCREW, HH, 5/16 x 1-1/4"Grade 5
2
7
055089
BUSHING
1
47
063003
LOCKWASHER, 5/16"
2
8
031162
WASHER, Special
1
48
065015
NUT, Hex, 5/16"
2
9
069100
CABLE, 24-7/8" Long
1
49
061044
SCREW, Machine Fillister Hd, 5/16 x 2-1/2
2
10
031261
ARM
1
53
074045
TAPPING SCREW
8
11
031260
CLEVIS
1
56
063024
LOCKWASHER
8
12
075046
GROMMET
1
58
031575
SHIFT SHAFT
1
13
031127
SPACER
2
60
065018
NUT
1
14
031567
RH FRICTION ANGLE
1
61
031100
LOCK PIN GUIDE
1
15
031566
LH FRICTION ANGLE
1
62
031099
PIVOT PLATE
1
16
059023
CAP SCREW, HH, 3/8"
X
3/4"
1
63
031098
PIN
1
17
083125
SPRING, 1-1/2 Long
2
64
064128
WASHER, Special
1
23
031024
BRACE
1
65
083121
SPRING
1
26
063021
LOCKWASHER,3/8"
6
66
031097
PIN
1
27
064008
WASHER, Flat, 3/8"
2
67
056075
"0" RING
1
28
065018
NUT, Hex, 3/8"
5
68
067024
PIN, Cotter, 1/8
X
3/4
1
29
059135
CAPSCREW 5/16-18
X
3/4 GR.5
1
70
031724
SHIFT LOCK
1
30
065101
LOCKNUT, Hex, 5/16
1
71
067034
COTTER PIN
2
31
058003
ROLL PIN, 3/16
X
1-1/4
2
72
083149
SPRING
1
34
062013
CARRIAGE BOLT
3
73
069110
CLAMP
1
36
031167
GASKET
1
74
059004
SCREW
1
37
083120
SPRING
1
75
064002
WASHER
2
38
058005
PIN, Spring 3/16x7/8
2
76
063021
LOCKWASHER
1
39
064003
WASHER, Flat, 1/2"
4
77
065018
NUT
1
40
064043
WASHER, Flat, 3/8"
5
