DASH, CONTROLS AND ELECTRICAL
MODELS 931013-18
REF
NO. PART
NO.
DESCRIPTION SSSsS o o o o o
CO CO CO CO n
O) O) O) O) Oi
ir>
0
fo
01
REF
NO. PART
NO.
DESCRIPTION 5 5
CO CO
O) 03
CO r
o o o
03 O) S
U3
o
03
1 531058 DASH W/Decal 1 28 064127 WASHER, Flat 1/4" 4 4
531101 DASHW/Decal(18H.P. Only) _ 1 29 061012 MACHINE SCREW, No. 10-24 x 1/2 2 3
2 031150 SWITCH, Clutch
1 2 30 025172 SWITCH 1 1
3 031151 SWITCH, Lights 1 1 31 065032 NUT, Hex, 1/4" 8 8
4 065104 NUT, Jam, 1/2" 2 3 32 063029 LOCKWASHER, Internal Tooth, 9/16" 1 1
5 075068 KNOB, Switch 2 3 33 075061 GROMMET 1 1
6 031152 SWITCH, Ignition 1 1 34 063011 LOCKWASHER, External Tooth, No. 10 14 16
7 013157 KEY SET 1 1 35 065055 NUT, Hex, No. 10-24 14 16
8 065106 NUT, Special, 9/16" 1 1 36 031070 CLIP 2 2
9 031179 PTO Indicater & Wire Ass'y 1 1 37 064141 WASHER 4 4
031983 PTO Indicater & Wire Ass'y _ 1 38 065026 NUT 4 4
10 074043 SCREW, Self-Tapping, No. 10 x 1/2 4 4 39 063011 LOCKWASHERS 4 4
11 059001 CAPSCREW, HH, 1/4 X 3/4 8 8 40 531074 RELAY - Diode 1 1
12 069103 CHOKE CONTROL ASS’Y 1
_ 031976 RELAY-Diode 18 H.P. Only
-
1
069115 CHOKE CONTROL ASS'Y, 18 Only 1 41 031716 SEAT SWITCH 1 1
13 069104 THROTTLE CONTROL 1
_ 42 031833 BRACKET-Switch 1 1
069116 THROTTLE CONTROL, 18 Only
_
1 44 075045 RUBBER BOOT 1 1
14 075019 KNOB, Throttle Control 1 1 45 023478 CONNECTOR HOUSING, 5 Wire 1 1
15 031085 BATTERY, 12 Volt 1 1 46 023595 CONNECTOR HOUSING, 4 Wire 1 2
16 031111 CABLE ASS'Y, Solenoid to Starter 1 1 47 031106 CONNECTOR HOUSING, 3 Wire 1 1
17 031720 SOLENOID STARTER SWITCH 1 1 48 031895 CONNECTOR HOUSING, 2 Wire 1 1
18 031117 AMMETER 1 1 49 031105 CONNECTOR 1 1
19 031107 SWITCH, Safety (Hydro Models)1 1 50 031149 HEAD LIGHT 2 2
029131 SWITCH, Safety Gear Models 1 1 51 031159 RETAINER RING 2 2
20 075057 INSULATOR 1 1 52 061040 SCREW, Machine, Truss H. No. 10-1/2" 8 8
21 065071 NUT, Special, 5/8" (Hydro Models) 1 1 53 064001 WASHER 8 8
065096 NUT, Gear Models 1 1 54 631006 TAIL LIGHT
2 2
22 031102 CIRCUIT BREAKER, 20 Amp 1 1 BULB - for item 54GE 1895 (not ill.)
2 2
23 031108 CIRCUIT BREAKER, 6 Amp 1 2 031375 LENS ' Red for item 54 (not ill.) 2 2
24 031110 CABLE ASS'Y, Battery to Solenoid 1 1 55 031962 HOUR METER, (Model 931015 Only)
1
25 031103 CABLE ASS'Y, Battery to Ground 1 1 56 075063 BOOT, Switch
1 1
26 031109 REGULATOR RECTIFIER 1 -
57 030006 SPACER, (For use with Dash
27 063002 LOCKWASHER, 1/4" 8 2 No. 531058 Only) 1 1
11
