DASH, DASH CONTROLS & ELECTRICAL
MODEL NO. 931004-6
I
REF
NO.
PART
NO.
DESCRIPTION
NO.
REQ'D.
REF
NO.
PART
NO.
NO.
DESCRIPTION
1
531001
DASH W/Decal
1
30
063002
LOCKWASHER, 1/4"
9
2
078266
DASH DECAL
1
31
064127
WASHER, Flat 1/4"
6
3
031150
SWITCH' Clutch
1
32
031114
WIRE HARNESS, 6-1/2" Long (Blue)
4
031151
SWITCH, Lights
1
Circuit Breaker to Light Switch
1
5
065104
NUT, Jam, 1/2"
2
33
031112
WIRE HARNESS, 10" Long (Orange)
6
075068
KNOB, Switch
2
Ignition to Clutch Switch
1
7
031152
SWITCH, Ignition
1
34
031113
WIRE HARNESS, 7-1/2" Long (Black)
8
013157
KEYSET
1
Circuit to Clutch Switch
1
9
065106
NUT, Special, 9/16"
1
35
031115
WIRE HARNESS, 14-1/2" Long (Black)
10
031179
PTO IndicatarSi Wire Ass'y
1
Ignition to Circuit Breaker
1
11
074043
SCREW, Salt-Tapping, No. 10 x 1/2
4
36
065032
NUT, Nex, 1/4"
9
12
059001
CAP SCREW, HH, 1/4 X 3/4
9
37
031104
WIRE HARNESS, 30" Long (White)
13
069103
CHOKE CONTROL ASS'Y
1
Ground for Head Lights
1
14
069104
THROTTLE CONTROL
1
38
063029
LOCKWASHER, Internal Tooth, 9/16"
1
15
075019
KNOB, Throttle Control
1
39
061040
SCREW, Machine, Truss, Hd. No. 10 x 1/2 2
16
031085
BATTERY, 12 Volt
1
40
075061
GROMMET
1
17
031111
CABLE ASS'Y, Solenoid to Starter
1
41
023478
CONNECTOR HOUSING, 5 Wire
1
18
029132
SOLENOID STARTER SWITCH
1
42
023595
CONNECTOR HOUSING, 4 Wire
1
19
031117
AMMETER
1
43
031106
CONNECTOR HOUSING, 3 Wire
1
20
031107
SWITCH, Safety
1
44
031105
CONNECTOR HOUSING, 2 Wire
2
21
075063
BOOT
1
45
063011
LOCKWASHER, External Tooth, No. 10
4
22
065071
NUT, Special, 5/8"
1
46
065055
NUT, Hex, No. 10 -32
4
23
031102
CIRCUIT BREAKER, 20 Amp
1
47
031101
WIRE CONNECTOR
4
24
031108
CIRCUIT BREAKER, 6 Amp
1
48
031070
CLIP
2
25
031110
CABLE ASS'Y, Battery to Solenoid
1
49
031168
WIRE ASS'Y,44-1/2" Long
1
26
031103
CABLE ASS'Y, Battery to Ground
1
50
031119
WIRE, Ignition to Rectifier (Blue)
1
27
031109
REGULATOR RECTIFIER
1
51
031118
WIRE, Coil to Ignition (Blue)
1
28
031116
WIRE HARNESS - 5 Wire
1
52
064141
WASHER
4
29
031147
WIRE HARNESS, 35" Long (White)
1
53
065026
NUT
4
Ground for Tail Lights
54
063011
LOCKWASHERS
4
55
631006
TAIL LIGHT (931004,5,6)
BULB G.E. 1895
LENS ARIENS No. 31375
2
I
