48” SNO-THRO PARTS LIST MODEL 831010
Serial No. 000101 - 006000
REF.
NO.
PART
NO.
DESCRIPTION
NO. REQ'D
REF.
NO.
PART
NO.
DESCRIPTION
NO. REQ'D
1 531077 SNO-THRO HOUSING, 48" w/Decals 1 96 074054 TAPTITE 6
5 065042 LOCKNUT 10 97 074027 TAPTITE 2
7 065122 LOCKNUT 4 98 531096 DEFLECTOR CHUTE 1
8 029225 SKIOSHOE 2
99 059023 CAP SCREW, 3/8-16 X 3/4 Gr. 2 HHPL 2
11 064002 WASHER, 5/16 Std. x 7/8 x .083 PL 6 100 062010 CARRIAGE BOLT, 3/8-16 x 3/4 SHRT PL 1
12 065039 LOCKNUT 8 101 010193 WING NUT 1
45 022093 SPIN DRIVE ZERK FITTING 5 102 031871 CABLE 1
49 010184 BEARING SUPPORT 2 103 063023 LOCKWASHER 2
SO 055035 BUSHING, Flanged 1 x 1-1/8 x 5/8 BR 2 104 062017 CARRIAGE BOLT, 1/4-20x5/8 2
51 070011 RIBBED NECK BOLT 6 105 031901 COVER 1
52 065056 FLANGE WHIZLOCK NUT 7 106 059028 CAPSCREW 2
53 064047 WASHER, .506/.516 x 1.441 x 1/8 PL 2 107 031892 CLIP 1
54 063006 LOCKWASHER 2 108 065078 FLANGE WHIZLOCK NUT 1
55 059024 CAP SCREW, 1/2-13x1 Gr2HHPL 2 109 031873 BELT GUARD 1
57 031860 BEARING FLANGE 1 110 031910 LIFT STRAP 2
58 054052 BALL BEARING 1 111 031875 SHAFT 1
59 065040 LOCKNUT 3 112 064140 WASHER, 5/8 Standard x 1-3/4 x .134 2
60 066001 KEY, Woodruff SAE 11,3/16 x 7/8 1 113 067014 COTTER PIN,1/8x1-1/4 PL 2
61 073102 SHEAVE 1 114 031876 LIMITING POST 1
62 031S61 SPACER 1 115 031877 LIMITING ARM 1
63 031862 SHEAVE 1 116 064003 WASHER, 1/2 Std. 2
64 054073 RADIAL BEARING 4 117 067029 HAIRPIN, Int. 3/32x1-7/8 PL 2
65 059004 CAP SCREW, 3/8-16x1 Gr.2HHPL 1 118 031878 CHUTE CRANK 1
66 0640081 WASHER, 3/8 Std. xT X .083 PL 1 119 075039 GRIP 1
67 063021 LOCKWASHER 1 120 010198 CAP 1
68 631128 UNIVERSAL SHAFT ASSEMBLY 1 121 067010 HAIRPIN 1
69 031863 UNIVERSAL HALF 1 122 031903 SUPPORT 1
70 031864 UNIVERSAL HALF 1 123 062029 CARRIAGE BOLT, 3/8-16x1 2
71 063002 LOCKWASHER 5 124 065023 WING NUT 2
72 059001 CAP SCREW, 1/4-20 x 3/4 Gr. 2 HHPL 7 125 067020 HAIRPIN 4
73 067030 PIN HAIR, INT, 3/16x3-1/4 PL 1 126 069003 CLAMP 1
74 059190 CAP SCREW, 3/4-10 x 5’^ Gr. 2 HH 1 127 064161 WASHER, 3/4 I.D. x 1.250 O.D. x .060/.063 1
75 064048 WASHER, .750/760 x 1.375 x .062 PL 2 128 064119 WASHER, 25/32 I.D. x 1-1/4 O.D. x .025 1
76 055104 SPACER 2 129 031920 LATCH 2
77 031865 IDLER ARM 1 130 059069 CAPSCREW 2
78 031866 SHEAVE 1 131 025135 SPACER 2
79 031867 BEARING SPACER 1 132 006071 SPACER 2
80 031868 IDLER ARM 1 133 083177 SPRING 2
81 065125 FLANGE LOCKNUT 1 134 031921 SPRING ARM 2
82 031896 TUBE 1 136 064096 WASHER, Flat, Special 2
83 073054 IDLER 2
137 012268 STUD 2
84 064131 WASHER, .401/.421 x 7/8 x 10 Ga. 2
138 065046 LOCKNUT 2
85 059005 CAP SCREW, 3/8-16 X 1-1/4 Gr. 2 HHPL 2
139 031911 SUPPORT 2
86 083126 EXTENSION SPRING 2
140 070015 FLANGE WHIZLOCK SCREW, 5/16-18 x 1/2 4
87 072095 V BELT 1
141 013315 CLEVIS PIN 2
88 072096 V BELT 1
142 065032 NUT, 1/4-20 2
89 031900 SPOOL 1
143 064127 WASHER 2
90 031891 SPHERICAL WASHER 1
91 083169 COMPRESSION SPRING 1
92 064139 WASHER, 41/64 I.D. x 1-1/4 O.D. x 3/16 1
93 067014 COTTER PIN, 1/8 X 1-1/4 PL 1
94 031930 DISCHARGE CHUTE 1
95 010438 CHUTE CLAMP 4
