REAR PTO KIT-MODEL 731014 (
rt
S 931004,5,6.8,9,
10,15,16,17,18)
REF
NO. PART
NO.
DESCRIPTION
NO
REQ'D
1 63lli)4 PTOSHAfT 1
2 054110 BEARING, Ball 1
3 031315 COLLAR 1
4 031020 FLANGETTE 2
5 031530 COVER 1
6 031571 SHIELD 1
7 031305 SNAP FASTENER 1
8 074041 SCREW, Self tapping, HH, 5/16 x 3/4 2
9 064002 WASHER, Flat, 5/16 2
10 061050 SCREW, Machine, R.H. No. 10 x 1" 1
11 063026 LOCKWASHER, Ext. Tooth, No. 10 1
12 064141 WASHER, Flat, 3/16 1
13 065055 NUT, Hex, No. 10 1
14 059093 CAP SCREW, Hex, S.H. 1/4-20 x 3/4 1
15 063002 LOCKWASHER, 1/4" 1
16 059134 CAPSCREW, 5/16" X 1-1/4" 4
17 064123 WASHER, Flat, 5/16" 4
18 065101 NUT, Crown Lock 5/16" 4
19 031075 SPACER COUPLING 3
20 031528 HUB 1
21 059174 CAP SCREW, H.H. 1/4-20 x 2" Gr. 5 1
22 065070 LOCKNUT, 1/4-20 1
23 031707 ADJUSTING PLATE 3
