Ariens 931 - Manual (Page 64)

MAIN DRIVE MODELS 931019, 22, 25 & 26
USED ON FOLLOWING MODELS
Model No.
931019
931022
931025
931026
Serial No.
005500 and up
002500 and up
000600 and up
001000 and up
REF.
NO. PART
N0. OESCRIPnON NO. REO’D
REF.
NO. PART
NO.
DESCRIPTION NO. REO’D
1 631184 Transmission 1 40 030139 Stud, Threaded 3
2 031480 Gasket 1 41 065122 Locknut, 3/8-16, Gr. C 4
3 631261 Link Ass'y 1931019, 931026) 1 42 057012 Snap Ring 2
4 064003 Washer, SAE 1/2-17/32" ID x 1-1/16" 43 030140 Coupling 2
OD X 3/32" 1 44 064123 Washer, Flat, 5/16" 8
5 059006 Cap Screw, HH 3/8" x 1-1/4" 1 45 059034 Cap Screw, HH, 5/16" x 7/8" 8
6 631177 Axle 1 46 065042 Locknut, Hex, 5/16" 8
7 030038 Street Elbow, 1/2" x 90° 1 51 031570 Support 2
8 001137 Plug, Pipe, 1/2" 1 52 031577 Cam 1
9 063021 Lockwasher, 3/8" 9 53 031572 Pivot Rod 1
10 062082 Carriage Bolt, 5/16-18 x 2-1/4" 1 57 054149 Ball Bearing 1
12 064041 Washer, Special 1 58 030397 Eccentric 1
13 003328 Wave Washer 2 59 083196 Spring, 2-13/16" Long 1
16 030148 Coupling 1 62 030398 Detent Arm 1
17 059048 Cap Screw, 3/8-16 x 7/8" HH 4 65 059132 Cap Screw, HH, 1/4" x 1" 1
18 075088 Hub Cap 2 66 065040 Nut, Hex, 1/4"-20 Center Lock 3
19 030065 Hose Clamp 2 71 058038 Roll Pin 1
20 031573 Push Nut 1 72 065043 Nut, (931019, 931026) T
21 030153 Drive Coupling 1 74 031995 Fan 1
21 030154 Drive Coupling (931019, 931026) 1 76 030037 Nipple 1
22 030149 Drive Hub, 1931019, 9310261 1 77 066003 Key, No. 9 Woodruff 3
23 631133 Tire & Wheel Ass’y (Consists of 2 78 030141 Lock Stud (931019, 931026) 1
24 071119 Tire, 23 X 10.50-12 79 060001 Setscrew, 3/8-16 x 1/2" (931019,
25 071106 Wheel W/Valve 931026) 1
26 065114 Lug Nut 10 80 030150 Drive Shaft, (931022) 1
27 031618 Filter Union 1 030152 Drive Shaft, (931019, 931926) 1
28 031928 Filter, Oil 1 81 058066 Pin 2
29 030066 Wheel Stud 10 82 070060 Ribbed Neck Cap Screw, 5/16" x 7/8" 2
30 030063 Connector 1 83 030149 Coupling (931022) 1
31 030062 Connector, Male 1 030155 Coupling (931019, 931026) 1
32 031487 Spacer 2 84 065062 Nut, Nylon Lock, 5/16-18 1
33 030414 Spacer 2 86 056047 "0" Ring 1
34 030064 Hose, 5/8" X 7-5/8" 1 87 064057 Washer, 5/16" 2
35 062047 Carriage Bolt, 1/2-13 x 1-1/4", Gr. 5 5 88 030399 Shift Arm 1
36 065127 Locknut, 1/2-13 5 89 059140 Cap Screw, 5/16" x 1-1/2" 1
37 030396 Mount Bracket 1 90 067001 Pin, Cotter 3/32" X 3/4" 1
38 030399 Shift Arm 1 91 030400 Rod, Neutralizer 1
39 059175 Cap Screw, 3/8-16 4
63
