REAR BRAKE & NEUTRALIZER ASSEMBLY
MODELS 931015, 931016, 931017, & 931018
REF.
NO,
PART
NO.
DESCRIPTION
NO. REQ'D
REF.
NO.
PART
NO.
DESCRIPTION
NO. REQ'D
1 031679 TORQUE, Spider 2 36 031506 NEUTRALIZER ROD 1
2 031678 DUSTSHIELD 2 37 031674 BRAKE DRUM 2
3 531039 BRAKE SHOE (sold in sets of two only) 2 38 083122 SPRING 2
4 031680 PIVOT NUT 2 39 065046 LOCKNUT, Hex 1/2" 4
5 031682 SOCKET, Adjusting Screw 2 40 065018 NUT, Hex 3/8" 5
6 083162 SPRING, Adjusting Shoe 2 41 063021 LOCKWASHER,3/8" 1
7 083161 SPRING,Shoe Return, L.H. 2 42 075051 PEDAL PAD 2
8 083160 SPRING, Shoe Return, R.H. 2 43 059030
CAP SCREW, HH 3/8" X 2-1/4" 1
9 031576 ROD, Shift 1 44 031505 ARM, Brake 1
10 031681 ADJUSTING SCREW, (star wheel) 2 45 031503 NEUTRALIZER ARM 1
11 067032 HAIR PIN RETAINER 4 46 031502 NEUTRALIZER PLATE 1
12 031675 STRUTS. LEVER ASSEMBLY 2 47 064042 WASHER, Special 2
13 031677 - PIN 2 48 055095 BUSHING 2
14 064156 WAVE WASHER 2 49 064002 WASHER, 5/16" 2
15 031702 RETAINER CLIP 2 50 031504 R.H. PEDAL 1
16 067001 PIN, Cotter 4 51 065042 LOCKNUT, Hex 5/16" 2
17 031507 BRAKE LATCH 1 52 025135 SPACER 2
18 059001 CAPSCREW, HH, 1/4" X 3/4" 1 53 067001 PIN, Cotter 3/32" X 3/4" 2
19 064127 WASHER, Special 1 54 064058 WASHER, Flat 3/4" 2
20 011091 SPACER, Bushing 1 55 031676 PARK BRAKE LEVER 2
21 065040 LOCKNUT, Hex, 1/4" 1 56 064057 WASHER, 5/16" 2
22 031935 BRAKE ROD 2 57 064043 WASHER, Flat 3/8" 7
' 23 031939 BRAKE ARM 1 58 064048 WASHER 2
I 24 031940 ARM 1
59 083055 SPRING 1
25 031938 BRAKE ARM 2
60 067029 HAIRPIN 1
26 031508 BRAKE ROD 1
61 031936 BAL. LINK 1
27 067004 PIN, Cotter 1/8x1 1
62 031937 CLIP 1
28 058040 PIN, Drive 1/4" X 1-1/4" 2
63 013303 CLEVIS PIN 2
29 031941 BRAKE SHAFT 1
64 631107 R.H. BRAKE ASSEMBLY 1
30 031509 PLATE 2
631108 L.H. BRAKE ASSEMBLY 1
31 059003 CAPSCREW, HH 5/16" 2
65 075055 GROMMET 2
32 063004 LOCKWASHER,3/8" 4
66 064062 WASHER AR
33 062013 BOLT, Carriage 3/8" x 1" 4
34 067006 PIN, Cotter 3/16" X 1-1/4" 2
35 031501 L.H. PEDAL 1
I
i
33
