Ariens 931 - Manual (Page 68)

REAR AXLE MODELS 931019, 22, 23, 24, 25, & 26
REF.
N0. PART
N0. DESCRIPTWN N0. REO’D
REF.
NO. PART
NO. DESCRIPTION NO. RED’D
1 031970 Rear Housing 1 30 031651 Side Gear 2
2 531052 Front Housing W/Bearing Cap 1 31 064154 Throw Washer 2
3 059181 Cap Screw, Hex Head, 5116" x 1" Gr. 5 8 32 031652 Bevel Mate Gear 2
4 063018 Lockwasher, External Tooth, 5116" 8 33 064155 Thrust Washer 2
5 065015 Hex Nut, 5/16" 8 34 031653 Pinion Mate Shaft 1
6 031637 Dowel Pin, 1/4" X 3/4" 2 35 031654 Lock Pin 1
7 031638 Housing Gasket 1 36 054132 Bearing Cone 1
8 031167 Gear Cover Gasket 1 37 054133 Bearing Cup 1
9 031100 Lock Pin Guide 1 38 031655 Rear Pinion Bearing Shim, .003 AR
10 074045 Self Tapping Screw, HH, No. 10 x 1/2" 8 031656 Rear Pinion Bearing Shim, .005 AR
11 031639 Vent Tube Assembly 1 39 031657 Spur Gear 1
12 631179 Wheel Hub W/Lug Bolts 2 40 031658 Front Pinion Bearing Spacer 1
13 065118 Nut, 7/8-14 2 41 054134 Bearing Cup 1
14 064163 Special Washer 2 42 054135 Bearing Cone 1
15 031641 Felt Seal 2 43 531049 Shim Kit (Consists of the following)
18 067005 Cotter Pin, 5/32" x 1-1/2" 2 031659 Front Pinion Bearing Shim, .031 AR
17 063024 Lockwasher, External #12 8 031660 Front Pinion Bearing Shim, .033 AR
18 031642 Wheel Bearing Gasket 2 031661 Front Pinion Bearing Shim, .035 AR
19 059193 Cap Screw, 5/16-24 x 1-1/4", Gr. 8 8 031662 Front Pinion Bearing Shim, .037 AR
20 054129 Bearing and Cone Assembly 2 031663 Front Pinion Bearing Shim, .039 AR
21 031643 Axle Shaft - Left Hand 1 031664 Front Pinion Bearing Shim, .041 AR
031644 Axle Shaft - Right Hand 1 031665 Front Pinion Bearing Shim, .043 AR
22 054130 Bearing Cone 2 031666 Front Pinion Bearing Shim, .045 AR
23 054131 Bearing Cup 2 031667 Front Pinion Bearing Shim, .047 AR
24 031645 Differential Bearing Adjusting Shim, .003 AR 031668 Front Pinion Bearing Shim, .049 AR
031646 Differential Bearing Adjusting Shim, .005 AR 031669 Front Pinion Bearing Shim, .051 AR
031647 Differential Bearing Adjusting Shim, .010 AR 031670 ^ Front Pinion Bearing Shim, .053 AR
031648 Differential Bearing Adjusting Shim, .030 AR 031671 Front Pinion Bearing Shim, .055 AR
25 031649 Differential Case 1 031672 Front Pinion Bearing Shim, .057 AR
26 N.A. Bearing Cap (This Cap is bolted to Ref. 44 057026 Retaining Ring 1
No. 2 and then machined as a matched 45 031673 Cup Plug 1
Assembly) 2 46 056093 Oil Seal 2
27 059126 Hex Head Cap Screw, 7/16" x 2" 4 47 030066 Wheel Lug Bolt 10
28 531050 Ring and Pinion Gear Set 1 48 065136 Whiziock, 5/16-24, Gr. C 8
29 070043 Special Bolt 10
