MAIN DRIVE
MODELS 931019, 931022, 931023, 931024, 931025 & 931026
USED ON THE FOLLOWING MODELS
MODEL
931019
931022
931023
931024
931025
931026
SERIAL NUMBER
000101 to 005500
000101 to 002500
000101 and up
000101 and up
000101 to 000600
000101 to 001000
REF.
NO. PART
NO.
DESCRIPTION
NO. REQ'D
REF.
NO.
PART
NO.
DESCRIPTION
NO. REQ'D
1 631184 Transmission 1 43 030140 Coupling 2
2 031480 Gasket 1 44 064123 Washer, Flat, 5/18 8
3 030036 Strap (931019, 931026) 1 45 059034 Cap Screw, HH, 5/16 x 7/8 8
4 064003 Washer 1 46 065042 Locknut, Hex, 5/16 8
5 059006 Cap Screw, HH 3/8 x 1 % 1 51 031570 Support 2
6 631177 Axle 1 52 031577 Cam 1
7 030038 Street Elbow, W x 90° 1 53 031572 Pivot Rod 1
8 001137 Plug, Pipe, 1 55 031492 Cam 1
9 063021 Lockwasher, 3/8" 9 56 057063 Snap Ring 1
10 062028 Carriage Bolt, Gr. 5 1 57 031137 Roller, %" O.D. 1
12 064041 Washer, Special 1 58 031023 Eccentric Pin 1
13 003328 Wave Washer 2 59 083116 Spring, 2-13/16 Long 1
16 030148 Coupling 1 60 031691 Hub 1
17 059048 Cap Screw, 3/8-16 x 7/8 HH 4 61 031493 Hub 1
18 075088 Hub Cap 2 62 031494 Pintle Arm 1
19 030065 Hose Clamp 2 63 064003 Washer, Rat, %" 1
20 031573 Push Nut 1 64 064043 Washer, Flat, 3/8" 1
21 030153 Drive Coupling 1 65 059132 Cap Screw, HH, % x 1 1
21 030154 Drive Coupling (931019, 931026) 1 66 065032 Nut, Hex, 3
22 030149 Drive Hub, (931019, 931026) 1 67 059162 Cap Screw, HH, K x 2" Gr. 5 1
23 631133 Tire & Wheel Ass'y (Consists of 2 68 064127 Washer, Flat, %" 3
24 071119 Tire, 23 X 10.50-12 69 063002 Lockwasher, )L" 1
25 071106 Wheel W/Valve 70 070015 Flange Whiziock Screw, K-20 x %" 1
26 065114 Lug Nut 10 71 058038 Roll Pin 1
27 031618 Filter Union 1 72 065043 Nut, (Model 931019, 931026) 1
28 031928 HIter, Oil 1 74 031995 Fan 1
29 030066 Wheel Stud 10 76 030037 Nipple 1
30 030063 Connector 1 77 066003 Key, No. 9 Woodruff 3
31 030062 Connector, Male 1 78 030141 Lock Stud (931019, 931026) 1
32 031487 Spacer 2 79 060001 Setscrew, 3/8-16 x % (931019, 931026) 1
33 031488 Spacer 2 80 030150 Drive Shaft, (931022 & 931023) 1
34 030064 Hose, 5/8 X 7-5/8 1 030152 Drive Shaft, (931019, 931026) 1
35 062047 Carriage Bolt, %-13 x 1% Gr. 5 5 81 058066 Pin 2
36 065127 Locknut 5 82 070060 Ribbed Neck Cap Screw, 5/16 x 7/8 2
37 031491 Bracket 1
83 030149 Coupling (931022, 931023) 1
38 031574 Pivot Bracket 1
030155 Coupling, (931019, 931026) 1
39 059175 Cap Screw 4
84 030141 Lock Stud (931019, 931026) 1
40 030139 Stud, Threaded 3
86 056047 "0" Ring 1
41 065122 Locknut, Gr. C 4
87 065018 Nut 1
42 057012 Snap Ring 2
61
