Ariens 931 - Manual (Page 2)

MODELS 931004 THROUGH 931018
DESCRIPTION PAGES DESCRIPTION PAGES
Decals 2,3 Rear Brake & Neutralizer 28,29,30,31,32,33
Il Electrical 4,5,6,7,8,9,10,11 Frame, Steering, Front Wheel 34,35
P Muffler, Fuel 12,13 Mechanical Lift 36,76,77
Hood, Grill 14 Hydraulic Lift, Front Rock Shaft 37,38,39
Rear Deck, Seat, Shift Linkage, Consoie 42
Dash Support, Running Board 16,17 Rear Rock Shaft 43
Main Drive - Hydro 18,19,20,21 Center Rock Shaft 44
Main Drive - Gear 22,23,64,65 Rear PTO 45
Rear Axle 24,25 Hydrostatic Controls, Console 40,41
Sundstrand Transmission 26,27 Front PTO 46
MODELS 931019 THROUGH 931026
DESCRIPTION PAGES DESCRIEIIQH PAGES
Decals 48,49,50,51 Rear Brake & Clutch - Gear 72,73
Electrbal 52,53,54 Frame, Steering, Front Wheel 74,75
Muffler, Fuel 55 Manual Lift 76,77
Hood, Grill 56 Hydraulic Lift, Front Rock Shaft 78,79
Rear Deck, Seat, Dash Support 58,59 Hydrostatic Controls, Console 80,81,82,83
Main Drive - Hydro 60,61,62,63 Shift Linkage & Consoie - Gear 84
Main Drive - Gear 64,65 Rear Rock Shaft 85
Rear Axle 66,67 Center Rock Shaft 86
Sundstrand Transmission 68,69 Rear PTO 87,88
Rear Brake & Neutralizer - Hydro 70,71 Front PTO 89,90,91
ATTACHMENTS
»
MODEL DESCRIPTION EA9ES
MODEL PESCRIPTIQN PAGES
831001 47" Mower 92,93,94,95,100 831010 48" Sno Thro 120,121,122,123
1831002 48" Mower 96,97,98,99,100 006000 & Up
831003 48" Sno Thro 102,103,104,105 831011 42" Mower 124.125.128
831004 54" Front Blade 101 831012 48" Mower 126,127,128
831005 34" Tiller 106,107,108,109,110 831016 Five-In-One 129,130,131
831006 34" Tiller 106,107,108,109,110 831026 60" Mower 128,132,133
831007 Dump Trailer 111 831027 48" Tiller 134,135136,137,138,139
831009 48" Sno Thro 112,113,114
831010 48" Sno Thro 114,116,117,118,119
000101 -0006000
ACCESSORIES
i
MODEL DESCRIPTION PAGES MODEL DESCRIPTION PAGES
731003 Sleeve Hitch 140 731022 Hour Meter Kit 148
731004 Wheel Weights 141 731025 Remote Deflector Kit 149
731005 Tire Chains 141 731027 Rear PTO Kit 150
731010 540 Front PTO 142 731028 Counter Balance Kit 151
731014 Rear PTO Kit 143 731029 Electric Rear PTO Kit 152
731015 Tire Chains 141 731032 Boot Kit 153
731016 Sleeve Hitch 144 731033 Boot Kit 153
731018 Rear PTO Kit 145 731034 Boot Kit 153
731019 540 Front PTO 146,147 731046 Electric Rear PTO Kit 154,155
731020 Wheel Weight Kit 141
SERVICE KITS
MODEL DESCRIPTION PAGES MODEL PESCRIPTIQN PAGES
531099
531104
531105
531106
531118
531141 Interlock Module
Spindle Assembly
Spindle Assembly
Brake Equalizer
Front PTO Replacement Assembly
Front Electric Clutch
156
157
157
158
159
160
531154
531155
531156
531164
531168
531236 Front PTO Replacement Assembly
Front PTO Replacement Assembly
Linear Shift Kit
Carburetor Heater Package
Vac Bagger Parts Update
Interlock Module Service Assembly
161
162
163
164
165
166
