MAIN DRIVE
»
MODELS 931015, 931016, 931017, & 931018
REF.
NO.
PART
NO.
DESCRIPTION
NO. REQ'D
REF.
NO.
PART
NO.
DESCRIPTION
NO. REQ'D
1 631088 TRANSMISSION 1 36 065127 LOCKNUT 4
2 031480 GASKET 1 37 031491 BRACKET 1
3 031485 ELBOW, 90“, SWIVEL 1 38 031574 PIVOT BRACKET 1
4 064008 WASHER 1 39 059175 CAPSCREW 1
5 059006 CAPSCREW, HH, 3/8 X 1-1/4 1 40 059171 CAPSCREW 3
6 631145 AXLE 1 41 065018 NUT, Hex, 3/8" 2
7 031125 STREET ELBOW, 1/2” X 45“ 1 42 057062 RING, External Snap (S-12H, S-14H, S-16H) 2
8 001137 PLUG, Pipe, 1/2" 1 057012 RING, External Snap (S-18H only) 2
9 063021 LOCKWASHER,3/8" 7
43 031952 SPACER , Special 2
10 062013 CARRIAGE BOLT 2
44 064007 WASHER, Flat, 5/16 8
11 031516 SHAFT 1
45 059039 CAPSCREW, HH, 5/16 X 1/2 8
12 064063 WASHER, Special 1
46 065042 LOCKNUT. Hex. 5/16 4
064095 ■ WASHER, Special (Model 931015 only) 1
47 066003 KEY, Woodruff, 3/16x3/4 1
13 011113 WAVE WASHER 1
48 058007 PIN, Roll 1
003328 WAVE WASHER (Model 931015 only) 2
49 060012 SETSCREW,Sq. Hd., 5/16x 1 2
14 059056 CAPSCREW 1
50 031495 CONNECTOR 2
15 065040 LOCKNUT 1
51 031570 SUPPORT 2
16 031982 COUPLING 1
52 031577 CAM 1
17 059099 CAPSCREW 4
53 031572 PIVOT ROD 1
18 031987 TORQUE BRACE (Model 931015 only) 1
54 031951 OUTPUT COUPLING 1
19 631153 SHAFT, W/Roll Pin 1
55 031492 CAM 1
20 031573 PUSH NUT 1
56 057063 SNAP RING 1
21 031978 DRIVE COUPLING 1
57 031137 ROLLER, 1/2" 0.0. 1
22 031515 FAN 1
58 031023 ECCENTRIC PIN 1
23 631002 TIRE 8* WHEEL ASS'Y, Consists of 2
59 083116 SPRING, 2-13/16 Long 1
24 071105 TIRE, 23 X 10.50-12 1 ) Models 931015
60 031691 HUB 1
25 071106 WHEELW/Valve 1 1 931017 8(931018
61 031493 HUB 1
23 631097 TIRESi WHEEL ASS'Y Consists of 2
62 031494 PINTLE ARM 1
24 071114 TIRE 1 i .. __________________________
63 064003 WASHER, Flat, 1/2" 1
25 071115
> Model 931016 Only
Rllvl 1 I
64 064043 WASHER, Flat, 3/8" 1
26 065114 LUG NUT 10
65 059132 CAPSCREW, HH, 1/4x1 1
27 031618 FILTER UNION 1 66 065032 NUT, Hex, 1/4" 3
.28 031928 FILTER, Oil 1 67 059162 CAPSCREW, HH, 1/4x2", Grade 5 1
29 070044 LUG BOLT 10 68 064127 WASHER, Flat, 1/4" 3
30 031489 ELBOW, 90“ "0" Ring 1 69 063002 LOCKWASHER, 1/4" 1
31 031484 : CONNECTOR, Male 1
70 070015 FLANGE WHIZLOCK SCREW, 1/4-20 x 1/2" 1
32 031487 SPACER 2
71 058038 ROLL PIN 1
33 031488 SPACER 2
72 065043 NUT, (Model 931015 Only) 2
34 031490 TUBE, Assembly 1
73 531094 DRIVE SHAFT ASSEMBLY 1
35 062014 CARRI/\GE BOLT Grade 5 4
74 031995 FAN 1
