SUNSTRAND TRANSMISSION
MODELS 931004-10 & 15-18
REF. PART
NO. NO.
DESCRIPTION
NO. REQ'D
REF.
NO. PART
NO.
DESCRIPTION
NO. REQ'D
1 054128 ROLLER BEARING 1 28 056091 LIPSEAL 2
2 054126 NEEDLE BEARING 2 29 054054 NEEDLE BEARING 1
3 056089 LIPSEAL 2 30 031617 CHG PUMP HOUSING 1
4 064151 WASHER 2 31 031631 PIN, Dowell 1
5 031615 TRUNNION SHAFT 1 32 531034 ROTOR ASSEMBLY 1
6 057069 RETAINING RING 2 33 056092 "0" RING
7 059180 CAPSCREW, 12 Pt. 2 34 059179 CAPSCREW, 12 Pt. GR.5 2
8 031624 HOUSING 1 36 083159 RELIEF VALVE SPRING 1
9 031629 GASKET 1 37 059133 CAPSCREW,HexHd.Gr. 5 1
10 031632 PIN, Dowell 2 40 531076 CHECK VALVE ASSEMBLY 2
11 031623 MOTOR SHAFT 1 44 031633 PIN, Headless Star 2
12 031622 SWASHPLATE 1 45 031628 PUMP VALVE PLATE 1
13 531035 CYLINDER BLOCK KIT 2 46 031627 THRUST PLATE 1
14 031621 - MOTOR VALVE PLATE 1 47 058062 COILED SPRING PIN 3
15 054127 NEEDLE ROLLER BEARING 2 48 031626 VAR. SWASHPLATE 1
16 031611 HEX HEAD PLUG 2 49 031616 PUMP SHAFT 1
17 056088 "0" RING 2 50 054071 BALL BEARING 1
18 031613 SHIM PACK A/R 52 031614 TRUNNION SHAFT 1
19 083157 RELIEF VALVE SPRING 1 53 059151 CAPSCREW, Hex Hd. GR.5 1
20 031609 RELIEV VALVE CONE 2 54 031630 PIPE PLUG 2
21 059147 HEX HEAD CAPSCREW GR.5 4 55 056096 "0" RING 2
23 031608 THREADED PLUG 2 56 056097 "0" RING 2
24 031618 FILTER UNION 1 57 056098 WASHER 2
25 059126 HEX HEAD CAPSCREW 2
26 031619 CENTER SECTION 1
27 064153 FLAT WASHER 2
»
►
27
